With a few mouse clicks only and using the PLC variables the visualization elements can be animated to perform simple movements or provide multitouch functionality. Or use the available generic elements and flexibly customize them to suit your needs “FB instances“ from visualizations, array access from visualizations, real time data recording, extendable pool of visualization elements, call of PLC functions from the visualization etc.Ĭreate modern and professional visualization screens in no time using specialized visualization elements.

Extended functionality due to the integration in the IEC 61131-3 development software.

⇒ Absolute flexibility, execution on all sorts of clients, for example on the PLC Development System, on the PLC itself, on the internet browser (on tablets and smartphones with HTML5) or on a remote PC and if desired on different client platforms simultaneously

Display and operation on different visualization clients with the same data.

⇒ The created visualization screens can be reused for other tasks as often as required.

Visualization screens for machine and plant operation, for testing and commissioning.Application and visualization are supervised simultaneously. ⇒ Direct access to all application variables, due to the full integration in the IEC 61131-3 Development System, no tag list comparison required. ⇒ All work is done in the familiar PLC development environment interface

Developing the visualization in parallel to the PLC program.⇒ Design of complex visualization screens based on available visualization elements CODESYS Development System with integrated visualization editor.
